Cogeneration Equipment

One (1) used 1.05 MW Elliott Steam Turbine Generators Rebuilt Quantity of Two (2) available. Back Pressure Steam Turbine Model BYRH UG; Power: 1350 HP; Inlet Steam Pressure: 600 PSI; Steam Temp: 750 F; Exhaust Pressure: 155 PSI. Generator Set is complete with Turbine Gearbox and Generator mounted on steel frame skid.

Donaldson Air Inlet Filter designed for operation with the Taurus 70 Solar Gas Turbine. Built for Solar Turbines. Includes Chiller for Inlet Air to keep temperature at 59F. Year NOV 2011. Weight 5783 Lbs. Dry / 7983 Wet.

WHRU – Rentech Hot Water Boiler rated for 690,000 lbs. water an hour (1,377 GPM). A combustion exhaust stream is used to heat approximately 690,000 pounds of water per hour from 170 °F to 225 °F at an ambient condition of 55 °F. Designed for use with a Solar Turbines, Taurus 70 Gas Turbine Generator.

Two (2) Thermax, Series 5G, single effect hot water driven vapor absorption chillers engineered to each produce 1015 tons of chilled water at 42 °F of using 17,374 MBH of recovered heat from a waste heat hot water boiler. Thermax Absorption Chillers, New 2012. The chillers will be capable of operating in-series as well as in parallel mode.

183600 Lbs/Hr Rentech HRSG Steam Boiler System New/Unused Surplus Equipment with 225 PSIG Design Pressure Year 2016. Comes with Supplemental Duct Burner Rated for 119.6 MMBtu/hr Fuel Natural Gas. Total Airflow Volume Capacity is rated for 367455 Lbs/Hr. This system was designed for operation with a Solar Titan 130 Gas Turbine. Under normal operating condition with a Titan 130 this HRSG will output 60000 Lbs/Hr. Steam without use of the Supplemental Duct Burner. Complete System Includes: Inlet Duct Duct Burner Burner controls and fuel skid Evaporator Outlet Duct Economizer Stack Ladders/Platforms Standard Boiler Instrumentation and Valves Feedwater Trim Deaerator / Feedwater Pumps all available engineering and documentation. Built in 2016.

46500 Lbs/Hr. Deltak HRSG 21 Tons/Hr steam flow 13.79 Bar (200 PSI) Operating Pressure 17.24 Bar (250 PSI) Design Pressure HRSG YOM 1996 in very good condition. HRSG includes the following equipment Diverter (bypass) Valve Economizer Boiler (Evaporator) Bypass Stack All transition Ducts Stack. Also can include a DA Tank and Feedwater Pumps. All Available Documentation Included.

250000 LB/HR; 900 PSI; Deltak HRSG designed for use with an LM6000 gas turbine generator unused surplus new in 2001. Includes Duct Burners. This heat recovery boiler produces both Low and High pressure super-heated steam. As originally delivered the Deltak HRSG included: Duct Burner – Natural Gas Fired; High and Low Pressure Boiler SuperHeater and Economizer; Complete Feedwater System; Valves; Support Structural Steel; Fuel Skid; Platforms Walk ways and Stack.

932 HP Elliott Steam Turbine with 655kw WEB Induction Generator. Year 2014. Turbine and Generator are mounted on a steel base frame. Turbine is powered by a Biomass Steam Plant. Steam conditions: 50,000 lb/hr. at 400 PSI / 448F Temperature. Inlet: 400 PSI; Exhaust: 150 PSI; Turbine speed: 3628 RPM.

655 kW Steam Turbine with Generator. System includes, Dresser-Rand Coppus RLHA 24 Turbine, Marathon Synchronous Generator, and Lufkin Speed Reducing Gearbox. Year 2013. Turbine Generator Skid: A common steel base is provided for the turbine, speed reducing gear and generator. The turbine and gear are coupled with a Lovejoy flexible stainless steel disc spacer type coupling, dynamically balanced to a maximum 2.5 mm/sec of vibration and meeting ISO G2.5. The generator and gear are coupled with a Lovejoy gear-type coupling with a 1.5 service factor. Coupling guards are installed over both couplings. Skid piping includes all piping necessary to collect condensate drains, steam leak offs and instrument air to single field connection point. Manual globe valves are installed in condensate drain lines for startup condensate removal. Skid wiring includes all conductors and conduit necessary to consolidate terminations for all skid instrumentation and control devices in a common terminal box.

7.5 MW Shin Nippon Machinery (SNM) Condensing Extraction Steam Turbine 60 Hertz. Model C5-R8-ER Type: Horizontal Impulse Multi-stage Multi-valve Axial flow and geared. Turbine Speed: 7477 RPM. Generator Speed: 1800 RPM. Electrical: 7500 kW / 60 Hz / 6.6 kV. Steam Characteristics: Inlet Flow: 93700 lb/hr; Temp: 725 F; Pressure: 440 PSI. Single Steam Extraction between 11000 – 55000 lbs/hr. at a pressure of 128 PSI. The turbine exhaust at 15 kg/cm2 is condensed. Package includes Synchronuous brushless AC generator by Shinko Japan; Gear Drive by SEISA Gear Japan; Turbine : Shin Nippon Machinery Japan; Control panel Auxiliary and some spare parts.

11.25 MW GE Model 10 Simple Cycle Turbines. Quantity (4) Units in Operation since 2001 with less than 700 total hours lifetime fired. Include Dry Low NOx plus SCR GE Air Cooled electric generators GE Speedtronic MKVI Controls. 14250 kva each / 13800 V / 10892 btu/kwh.

One (1) used 1000 KW Elliott Steam Turbine Generators Rebuilt Quantity of Two (2) available. Back Pressure Steam Turbine Model BYRH UG; Power: 1350 HP; Inlet Steam Pressure: 600 PSI; Steam Temp: 750 F; Exhaust Pressure: 155 PSI. Generator Set is complete with Turbine Gearbox and Generator mounted on steel frame skid.

28 MW GE Steam Turbine Generator. 32.4 MVA / 60 Hertz / 13.8 kV. New Steam Path 2007 Generator rewind in 2007 with GE Micapal winding insulation. Mark V Governor installed year 2000. Designed for 680000 PPH steam at the inlet with two (2) extraction points at 150 PSI and 60 PSI and the balance of steam is condensed. Includes all auxiliaries except excitor. Originally manufactured 1968. Well maintained with any available spares included.

7.4 MW Solar Taurus 70 Combustion Turbine Generator Package; Engine: T10801SA; SoloNox - Low NOx engine designed for Natural Gas fuel combustion. Hours: 12,205; Starts @ 125; Includes 7600 kw Kato Synchronous Generator; 12.47 kV; 9500 KVA; 3 Phase; 60 Hertz. Featuring on Package Controls, and a Donaldson Inlet Air Filter with Air Inlet Chiller. *** Also available are two (2) absorption chillers rated for 2000 Tons of cooling, an ammonia SCR and Catalyst system, as well as a Rentech hot water waste heat recovery boiler ***

Two (2) 4.6 MW Solar Turbines, Model Centaur 50-6201. Designed for Dual Fuel operation, (#2 Oil / Gas); Unused (New) Surplus; SoLoNOx Combustion System, 25/96 ppm NOx, Dual Fuel; Engine Model 6201SA. Generators are by Kato, 4160 V, 60 Hz, 1800 RPM. Direct Drive AC Start System.

45.3 MW Generation Capacity, Westinghouse / Seimens 251B 12A Gas Turbine Generator with steam cogeneration boiler, (HRSG). Year 1997. 60 Hertz / 13.8 kV. Natural Gas Fired. Dry Low NOx System. Last Hot Gas Path 2007. Speed 5427 RPM. Lufkin Gear Reducer to 3600 RPM. BRUSH Generator (brushless) 69.3 MVA, 0.85 pf, 13.8 kV. Capable of burning Fuel Oil. HRSG Boiler Specifications: 225,000 lbs/hr Steam @ 200 PSI (Unfired), 450,000 lbs/hr Steam @ 200 PSI (w/Supplemental Duct Burners). Superheated Steam Temperature of 450F Deg. HRSG Includes: Integral deaerator with LP drum/storage tank, Superheater, IP drum, IP boiler bank, economizer Desuperheater at SHO, CO catalyst. Equipment well maintained in very good condition. All documentation and controls included. Auxiliaries include 2 AC lube oil pumps, 1 DC lube oil pump, local control room, boiler feed pumps, 2400 V starting motor package, 480 V substation and MCC's, inlet NOx trim control, continuous emissions monitors, GT water wash skid, fire protection systems, WDPF II DCS for GT control, Bailey INFl-90 for balance of plant control, HVAC for control rooms.

3.0 MW Solar Centaur T4701 Open skid inside a building. 747 hour Turbine Engine. 1992 vintage package 3.0 mw Ideal generator- 4160 volt Generator breaker – MCC – battery charger fire and gas bottles Natural gas fired exhaust silencer PLC controls.

9.5 MW Solar Mars 90 T 13002S Turbine Generator; Hours: 1214 total lifetime. Fuel Natural Gas SoLoNOx Electricals: 3 PH / 60 Hz / 4160V Ideal Generator. System was Remanufactured by Solar Turbines in 2001 with a Zero-hour Engine Gearbox and Generator. Includes these Systems and Equipment: Solar Turbotronic TT3 MX Turbine Control System; (2) Sets Of Lube Oil Coolers; Turbine Air Inlet System (with silencer air duct to turbine and air chiller); Turbine exhaust expansion joint Generator air exhaust duct with silencer; Battery charger (2) Sets of fire suppression systems; Relay panel with breaker; Generator inlet air duct Enclosure ventilation air duct with silencer 480V Motor control center. Package was originally built in 1987.

5.2 MW Solar Taurus 60 Enclosed Generator Sets Quantity: Three (3). Electricals: 3Ph / 60Hz / 4160 Volt; Fuel: Natural Gas or Landfill Gas. New in 2001 with following Hours and Starts: Unit #1 - 15715 hours / 269 starts; Unit #2 - 20232 hours / 474 starts; Unit #3 - 15167 hours / 293 starts. Packages include the following equipment: Lube oil coolers fire cylinder cabinet neutral ground resistor switchgear Air intake housings oil filter skids exhaust spool pieces turbine exhaust stacks Donaldson air filters rain hood skids air intake ducts oil heater skids.
